JUKI MO-6714DA-BE6-40H β Industrial Double Needle Semi-Dry-Head High-Speed Overlock Machine (2.0 mm Gauge, 4.0 mm Overedging Width) for Medium to Heavy-Weight Materials
The JUKI MO-6714DA-BE6-40H is a 2-needle high-speed overlock machine from the MO-6700 series, designed for sewing medium to heavy-weight knit fabrics, including sweaters and thick knitwear. The machine produces class 514 overlock stitches, widely used for durable seam finishing and runstitching in knit garment production.
This configuration features a 2.0 mm needle gauge and 4.0 mm overedging width, ensuring precise seam formation and reliable edge finishing when working with thicker knit materials. The machine is specifically optimized for runstitching operations on knit fabrics, providing stable feeding and consistent seam quality.
The machine is equipped with semi-dry head technology, which significantly reduces oil splashes around the sewing area and minimizes the risk of oil stains on garments. This helps maintain cleaner sewing conditions and improves the quality of finished products.
Additionally, the upper looper extra-high throw mechanism improves stitch formation and fabric handling when sewing bulky knit materials or multi-layer seams.
With a maximum sewing speed of up to 7,000 stitches per minute, the MO-6714DA-BE6-40H offers excellent productivity while maintaining stable performance in demanding knitwear manufacturing environments.
What Sets the JUKI MO-6714DA-BE6-40H Apart
The MO-6714DA-BE6-40H combines the reliability of the JUKI MO-6700 series with advanced semi-dry lubrication technology, designed to significantly reduce oil splashes without compromising durability.
Only the mechanisms most likely to cause oil splashes β such as the needle bar and upper looper mechanisms β have been redesigned with dry technology. This allows the machine to maintain the durability of a conventional lubricated system while reducing oil contamination risks.
The machine also incorporates an upper looper extra-high throw system, which improves stitch stability and fabric handling when sewing thicker knit fabrics or bulky seams.
How Does This Machine Improve Your Production Workflow?
Semi-Dry Head Technology
Reduces oil splashes around the needle area, helping prevent oil stains on finished garments.
Designed for Knit Materials
Optimized for medium to heavy knit fabrics, including sweaters and thick knitwear.
Upper Looper Extra-High Throw
Improves stitch formation and seam stability when sewing bulky knit materials.
High Sewing Speed
With speeds up to 7,000 stitches per minute, the machine supports efficient high-volume production.
Stable Runstitching Performance
The configuration is designed for reliable runstitching operations in knit garment production.
Differential Feed Control
Allows precise adjustment to prevent stretching or puckering when sewing knit fabrics.
Enhanced Durability
Special surface treatments and optimized lubrication improve machine longevity.
Easy Maintenance
Grease filler openings are provided on key machine components for easier servicing.
Who Benefits Most
Knitwear manufacturers
Sweater and heavy knit garment production lines
Apparel factories sewing medium and heavy knit fabrics
Industrial sewing operations requiring durable overlock seams
High-volume knit garment manufacturing facilities
